Butterfly Valves
Industrial Butterfly Valves Manufacturer
Wefar Type Centric Disc Valves Manufacturer
Focet Valves Pvt. Ltd. is the Best Industrial Butterfly Valves Manufacturer, Industrial Butterfly Valves Exporter in Gujarat, and Industrial Butterfly Valves Wholesaler in Ahmedabad. We give you Best Industrial Butterfly Valves Prices in Ahmedabad.
|
Technical Specification
|
|
|---|---|
|
BODY
|
IS 210 GR. FG 200 CAST IRON / ASTM A GR 216 WCB
|
|
DISC
|
SG IRON / SS 304/ SS 316
|
|
SHAFT
|
AISI SS 304
|
|
SEAT
|
EPDM / NBR / VITON
|
|
MFG & STD
|
BS 5155 / IS 13095
|
|
INSP & TEST STD
|
BS 6755
|
|
ENDS
|
WAFER TYPE SUIT TO ASME B 16.5
|
|
OPEARATION
|
FLOW CONTROL LEVER / GEAR / PNEUMATI / ELECTRIC ACTUATOR OPERATED
|
|
HYD TEST PRESSURE
|
BODY : 225 PSIG (16 KG/CM 2)
|
|
|
SEAT : 165 PSIG (11.5 KG/CM 2)
|
|
SIZE RANGE
|
40 MM TO 1000 MM
|
Lugg Type Centric Disc Valves Manufacturer
|
Technical Specification
|
|
|---|---|
|
BODY
|
IS 210 GR. FG 200 CAST IRON / ASTM A GR 216 WCB
|
|
DISC
|
SG IRON / SS 304/ SS 316
|
|
SHAFT
|
AISI SS 304
|
|
SEAT
|
EPDM / NBR / VITON
|
|
MFG & STD
|
BS 5155 / IS 13095
|
|
INSP & TEST STD
|
BS 6755
|
|
ENDS
|
WAFER TYPE SUIT TO ASME B 16.5
|
|
OPEARATION
|
FLOW CONTROL LEVER / GEAR / PNEUMATI / ELECTRIC ACTUATOR OPERATED
|
|
HYD TEST PRESSURE
|
BODY : 225 PSIG (16 KG/CM 2)
|
|
|
SEAT : 165 PSIG (11.5 KG/CM 2)
|
|
SIZE RANGE
|
40 MM TO 600 MM
|
Double Flanged Centric Disc Valves Manufacturer
|
Technical Specification
|
|
|---|---|
|
BODY
|
IS 210 GR. FG 200 CAST IRON / ASTM A GR 216 WCB
|
|
DISC
|
SG IRON / SS 304/ SS 316
|
|
SHAFT
|
AISI SS 304
|
|
SEAT
|
EPDM / NBR / VITON
|
|
MFG & STD
|
BS EN 593 / API 609
|
|
INSP & TEST STD
|
BS EN 12266 (PART-1) / API 598
|
|
ENDS
|
FLANGED END SUIT TO ASME B 16.5 150#
|
|
OPEARATION
|
FLOW CONTROL LEVER / GEAR / PNEUMATI / ELECTRIC ACTUATOR OPERATED
|
|
HYD TEST PRESSURE
|
BODY : 225 PSIG (16 KG/CM 2)
|
|
|
SEAT : 165 PSIG (11.5 KG/CM 2)
|
|
SIZE RANGE
|
50 MM TO 600 MM
|
SPHERICAL BUTTERFLY VALVE DOUBLE OFF-SET DISC Manufacturer
|
Technical Specification
|
|
|---|---|
|
BODY
|
ASTM A216 GR WCB / ASTM A351 GR CF8(304) / CF8M(316)
|
|
DISC
|
ASTM A351 GR CF8(304) / CF8M(316)
|
|
SEAT
|
PTFE / GFT / CFT
|
|
SHAFT
|
AISI 410 / 304 / 316
|
|
MFG & STD
|
API 609
|
|
INSP & TEST STD
|
API 598
|
|
END
|
WEFAR TYPE SUIT TO ASME B 16.5 (150#)
|
|
OPEARATION
|
FLOW CONTROL LEVER / GEAR / PNEUMATI / ELECTRIC ACTUATOR OPERATED
|
|
HYD TEST PRESSURE
|
BODY : 300 PSIG (21 KG/CM 2)
|
|
|
SEAT : 160 PSIG (11 KG/CM 2)
|
|
SIZE RANGE
|
50 MM TO 600 MM
|
Butterfly Valves Centric Disc Investment Casting Manufacturer
|
Technical Specification
|
|
|---|---|
|
BODY
|
ASTM A GR 216 WCB / ASTM A GR CF8(304) / CF8M(316)
|
|
DISC
|
SS 304/ SS 316
|
|
SHAFT
|
AISI SS 304
|
|
SEAT
|
EPDM / NBR / VITON
|
|
MFG & STD
|
BS 5155 / IS 13095
|
|
INSP & TEST STD
|
BS 6755
|
|
END
|
WAFER TYPE SUIT TO ASME B 16.5
|
|
OPEARATION
|
FLOW CONTROL LEVER / GEAR / PNEUMATI / ELECTRIC ACTUATOR OPERATED
|
|
HYD TEST PRESSURE
|
BODY : 225 PSIG (16 KG/CM 2)
|
|
|
SEAT : 165 PSIG (11.5 KG/CM 2)
|
|
SIZE RANGE
|
40 MM TO 300 MM
|
|
Sailent Features
|
|---|
|
Rigid and Sturdy design with minimum loss of ahead across the valve.
|
|
Perfect Interchangeability of components.
|
|
Assured Parallelism of components.
|
|
Assured equal taper on both sides of the wedges.
|
|
Perfect Machining and pressing of body and wedge face ring.
|
|
Long service life and leak Tightness even after thousand of open/closed cycles.
|
|
Excellent finish on spindle threads resulting in low friction and smoother operation of valves.
|
